ARC WELDING ROBOT OTC FD-V8L

Name : ARC WELDING ROBOT OTC FD-V8L

Code : FD-V8L Long-Reach Robot (8kg payload, 2.0m reach)

Title :

FD-V8L 6-axis, long-reach robot is ideal for welding, air-plasma cutting or material-handling. This extended reach arm is ideal reaching large parts

Detail :

• Offers a wide working range with an independently articulated arm

• Seamless digital connection with all OTC DAIHEN brand welding power supplies

• Improved vibration restraining control provides smooth robot movement

• Built-in mechanical shock sensor for welding applications

• Single source technology – all components are manufactured by OTC Daihen.

• Highly versatile design supports most welding applications

• Windows XP based open architecture

• Large memory capacity and 40 Input / 40 Output control signals

• Advanced PLC functions allow for ladder diagram editing directly through the teach pendant

• Network capabilities – connects to Ethernet, DeviceNet, and PROFIBUS connections (may require additional hardware)

• Icon displays assist in quick & easy teaching

• 640×480 VGA color screen with LED backlight 65536 color display

• 3 position enable switch provides increased safety

• Multi-screen function allows user to view up to 4 screens simultaneously

• On-screen help function with complete instruction manuals

• Standard touch screen display with jog dial operation
